Ultraviolet Video Borescope

SKU: UV iSeries Videoscope
Interchangeable ultraviolet capable video borescope probes for the iTool Videoscope System. The UV Videoscope is available in 8mm diameters and lengths up to 3m (9.8 Ft). Perfect for dye penetrant applications that require inspection of remote areas.
Want to learn more about this product?
Typical Response Time: <1 business day

The AIT Advantage

×

Proud U.S. Government Supplier

We simplify purchasing for U.S. Government buyers by accepting Government Purchase Cards (VISA, MasterCard, American Express) and regular credit cards. We also offer Net 30 terms to most federal, state, and local agencies.

CAGE Code: 9U7N2

AIT is a Small Business, as defined by SBA Small Business Size Standards. Contact us to submit an RFQ or purchase order.

×

FREE Lifetime Tech Support

AIT is your partner for life. We’re here to help with any questions you may encounter after the purchase, for as long as you own the product.

×

AIT Authenticity Guarantee

Mission-critical projects demand top-quality equipment—there’s no room for error. AIT guarantees 100% authentic products, rigorously inspected to ensure manufacturer-direct quality. Trust AIT to eliminate the risks of counterfeit or compromised gear.

×

FREE Technical Consultation

At AIT, you'll speak directly with real experts who have decades of experience in visual inspection. Whether it's a hard-to-reach turbine blade, pipe, duct, or a circuit board, we offer solutions tailored to your unique needs.

Our expertise is available at no cost and with no obligation.

×

Flexible Financing Options

Get essential equipment now without waiting on budget cycles. Our flexible financing options turn capital expenses into operational costs, preserving your capital budget.

Getting a financing quote is quick, easy, and free. In just a few simple steps, you’ll have a tailored quote to help secure the equipment you need without delay. Contact us for more information.

Product Information
Specifications
Applications
Downloads

   Ultraviolet Video Borescope Overview

  • Diameters: 8.0mm (.815 in.)
  • Lengths: 1.0 to 3.0 meters (3.2 to 9.8 ft.)
  • 4-way tip articulation
  • One touch freeze/save button
  • Interchangeable tip optics
  • Tungsten braided insertion tube



Ultraviolet Video Borescope Features and Benefits

  • UV surface intensity measured at the work surface exceeds common commercial and MIL standards at greater than 2,000 uW/sq.cm. Referenced standards are based on a hand help UV lamp at a 15" working distance to the inspection surface. The light guide is integral.
  • UV videoscopes are designed with silica fibers of extremely efficient UV light transmission at the peak intensity of 365nm, desirable for FPI.
  • In the interest of longevity, given the nature of silica fiber, UV videoscopes are configured with 4-way, 90-degree articulation.
  • The UV videoscopes have been tested with other light sources offered domestically and offer comparable performance. We prefer to sell our light source, but if budget is an issue we can establish compatibility.
  • UV videoscopes are compatible with all IT Concepts video based documentation systems. The white objective is recommended for maximum magnification necessary for small defect analysis coupled with optimal coincidence of UV illumination and field coverage. All objectives are compatible.
  • The UV Video borescope allows inspectors to interchange different diameter and length probes with an iTool imaging HUB and UV light source.
  • 4-way articulation allows you to manipulate the video borescope in tight spaces where other rigid borescopes cannot view during UV dye penetrent applications.
  • One touch image/freeze capture allows you to record your inspection with ease.
  • High resolution Sony super HAD CCD imager means that you will see the smallest detail down to a hair-line crack.
  • Tungsten braided insertion tube make the Ultraviolet video borescope rugged to withstand any industrial inspection.
  • Insertion tube fluid resistance: water, mineral and synthetic oils, hydraulic fluids, aviation fuel, kerosene, gasoline and diesel fuel



Ultraviolet video borescope UV light transmission

Ultraviolet videoscope includes:

  • Objective Lens: 90° FOV White (110-0046)
  • Storage and shipping case

Ultraviolet Video Borescopes Overview

Diameters:  8.0mm

Working Lengths: 1.5m - 15m

Articulation: 4-Way

Articulation Angle* L/R | U/D: 90°/90°

Integrated Objective Lens: 6 and 8mm diameter probes

Side View Tip Adapter: Yes (4mm diameter probe: only with 60° FOV)

Braid: Tungsten Braid on PU-Jacket



UV Video Borescope Construction

System Weight: 2.25kg (4,96lb) Operating Unit iTool / 9.2kg (20lb)

Case Dimensions: 290mm x 190mm x 70mm

Housing: rugged PU

Frame: Alloy

Protection Class: IP53

Operating Environment

Tip Operating Temperature:

System Operating Temperature: -13°F to 115°F (-25°C to +45°C)

Storage Temperature: -13°F to 115°F (-25°C to +45°C)

Relative Humidity: 95% max. – Non-condensing

Waterproof: Probe and distal end up to 14,7 psi (1 bar- 10,2 m H2O)(not 6mmSVTA)

Hazardous Environments: Not rated for use in hazardous environments
